JEC Axial flow pumps size ranges from 6" to 20" having flow upto 30,000 m3/hr and Head upto 7  meters.



The Axial flow pump generates flow by the thrust or lift action of rotating axial vanes of the pump impeller. Axial flow propeller pump has an elbow that directs the flow through the suction and out to the discharge end of the pump. It can be used in top or end suction configuration depending on the need and flange dimensions, bolt circle and holes comply with ANSI B16.5 150 class. JEC axial flow pumps upto fourteen inch size (14") has a back pull out design for easy maintenance and repair as the rotating element can be removed without disturbing the pipe work. Pumps have wear rings as standard and lifting eye on the bearing bracket.  JEC offers axial flow pump with excellent construction feature of back pull out pump design.



Also casted and fabricated elbow are precisely machine having minimum gap between propeller and casing. Moreover the pump shaft is wet type coming in contact with the pumped liquid. Shaft sealing can be gland pack type or double mechanical seal with cartridge type arrangement.
